Vibration Transmitter Module VC-200A
This stand alone analogue module which applies dynamic signal protection meets the requirements of API-670.
likewise provides all the features of a standard vibration protection system able to excite relay output also transmit 4-20mA signal proportional to:
also acceleration, velocity, or displacement to PLC/DCS or any standard 3rd party recorder.
also BNC output for reading with portable data collectors,optional internal integrator,most noteworthy transducer check display LED, current loop check ,another alarm relay outputs are all provided in just one module.
also Optional selection between delays in alarm,energized and non-energized relays are also embedded.
Terminal for remote reset for alarm ignorance is also provided. It may be connected either to an ICP™ accelerometer or a proximity displacement probe and almost any type of vibration sensors.
as a result VC200A is a complete system which simply needs DC power supply and so connected transducer with easy setup.
• ICP® /Voltage/Current Transducer
• Acceleration/Velocity/Displacement input signal
• 4-20mA output of dynamic signal / overall value
• Buffer output signal
• ICP® sensor OK Function
• Current loop Error Function
• Delay Shutdown Function DIN Rail Mounted
• Energize and De-energize Relay Select
• Push-in type Connectors
• Acceleration/Velocity/Displacement input signal
• 4-20mA output of dynamic signal / overall value
• Buffer output signal
• ICP® sensor OK Function
• Current loop Error Function
• Delay Shutdown Function DIN Rail Mounted
• Energize and De-energize Relay Select
• Push-in type Connectors
Input : 100 mV/g constant current accelerometer (Other sensitivities available)
Frequency Range : 1 Hz to 10 kHz (-3dB) (Optional)
Filter : Butterworth force filter order 8-pole
Dynamic Range : 80 db
Signal Conditioner : Amplifier/integrator to obtain velocity or displacement response
Power Input : +24 V DC (50 mA)
Output 1 : 0-20 mm/s rms Velocity (other ranges available)
Output 2 (BNC) : Buffered acceleration output without Bias voltage
Relays Output : 1 SPDT, 1A Form C 24Vdc
LED Statuse : 4 LEDs Power, Loop, ICP, and relay
Frequency Range : 1 Hz to 10 kHz (-3dB) (Optional)
Filter : Butterworth force filter order 8-pole
Dynamic Range : 80 db
Signal Conditioner : Amplifier/integrator to obtain velocity or displacement response
Power Input : +24 V DC (50 mA)
Output 1 : 0-20 mm/s rms Velocity (other ranges available)
Output 2 (BNC) : Buffered acceleration output without Bias voltage
Relays Output : 1 SPDT, 1A Form C 24Vdc
LED Statuse : 4 LEDs Power, Loop, ICP, and relay
Case Material : Plastic
Mounting : DIN Rail TS35 (Top Hat)
Dimensions : 134 x 99 x 22.5 mm (H x D x W) including BNC
Connections : Push in Clamp
Conductor Size : 0.5 to 4.0 mm
Weight : 110 g (nom)
Mounting : DIN Rail TS35 (Top Hat)
Dimensions : 134 x 99 x 22.5 mm (H x D x W) including BNC
Connections : Push in Clamp
Conductor Size : 0.5 to 4.0 mm
Weight : 110 g (nom)
Operating temperature range : 0 to 55 ºC
Installation Category (IEC664) : II
Equipment Class (IEC536) : III
EMC : EN61326-1:2013
Installation Category (IEC664) : II
Equipment Class (IEC536) : III
EMC : EN61326-1:2013
VC-200A Vibration Module Signal Conditioner / Transmitter catalogue Download File.pdf
